MECHATROLINK-Ⅲ Network cable
Spec
- M-Ⅱ
- M-Ⅲ
- M-4
Peripheral Devices
電纜及連接器
Features
PNET/B from JMACS is a industrial Ethernet cable with the necessary shielding and EMI protection for MECHATROLINK-Ⅲ.
1. Transmission characteristic
・ISO/IEC11801 (Cat.5), TIA/EIA-568C.2 (Cat.5e)
2. Safety Standard
・UL/c-UL Listing (UL444 CM, CSA C22.2 No.214)
3. Environmental Regulation
・Lead-Free, Oil and heat resistant PVC jacket
・RoHS Directive REACH Regulation (SVHC)
4. Other Features
・Excellent flexibility
・Length marks imprinted on the cable make measuring easy.
1. Transmission characteristic
・ISO/IEC11801 (Cat.5), TIA/EIA-568C.2 (Cat.5e)
2. Safety Standard
・UL/c-UL Listing (UL444 CM, CSA C22.2 No.214)
3. Environmental Regulation
・Lead-Free, Oil and heat resistant PVC jacket
・RoHS Directive REACH Regulation (SVHC)
4. Other Features
・Excellent flexibility
・Length marks imprinted on the cable make measuring easy.
Specifications
| Item | Specifications |
|---|---|
| Cross Sectional Area | 22AWG (0.34mm2, Stranded Conductor) |
| No. of core | 2p (4c) |
| Insulation color | White, Yellow, Blue, Orange |
| Shield | AL/PET+Braid |
| Jacket color | Blue |
| Overall diameter (mm) | Approx. 6.5 |
| Approx.Mass (kg/km) | 60 |
| Max.Transmission Distance (m) | 100 |
| Connector | Industrial Mini I/O Connectors, RJ-45 |
